Description
Overview:
The MOTOMA Solis S6-EH3P (80–125KW) series is a three-phase, high-voltage energy storage inverter designed for robust commercial and industrial applications. It ensures uninterrupted power through advanced features like DC and AC coupling for flexible system retrofits and expansions, intelligent load management, and seamless integration with various power sources including solar, wind, and diesel generators. It is built for high efficiency and reliable performance even in demanding environments.
Main Features:
- High PV Input: Supports up to 2x the rated PV power input to maximize solar energy harvesting
- High Current Support: Features a maximum string input current of 21A, making it compatible with modern high-power PV modules.
- Fast Charging: Supports fast battery charging with a maximum current of 200A.
- Dual Battery Ports: Includes two independent battery ports for flexible configuration and easy capacity expansion.
- High Overload Capability: Delivers 160% overload for 200ms in off-grid mode to reliably start heavy loads.
- Parallel Operation: Supports multi-unit parallel connection for a total capacity of up to 1.25MW.
- UPS-Level Switching: Provides automatic off-grid transition in less than 10ms for an uninterrupted power supply to critical loads.
- Flexible Control: Offers advanced control for weak grid and generator-hybrid scenarios.
- Smart Management: Integrates PV and storage for demand management, anti-reverse power control, and dynamic reactive power compensation.
- Advanced Cooling: Utilizes patented cooling technology for reliable operation in high-temperature conditions.
- Monitoring: Equipped with a 7.0” LCD screen, Bluetooth, and an App for local and remote monitoring via CAN, RS485, Ethernet, and optional Wi-Fi/Cellular/LAN.
