Bateria de UPS

Pacote de Bateria LiFePO4 UPS 12,8V 20Ah

Bateria de UPS

Pacote de Bateria LiFePO4 UPS 12,8V 20Ah

Tipo de bateria: Bateria LiFePO4 12V 20Ah
Tensão nominal: 12,8V
Capacidade nominal: 20Ah
Dimensão: 181*77*167 mm
Peso: 2,2 kg
Módulo da bateria: Suporta bateria em série (4 unidades, máximo 51,2V)
Não suporta bateria em paralelo
Certificação: UL / IEC / CE / UN38.3 / MSDS

Category
Bateria de UPS

Pacote de Bateria LiFePO4 UPS 12,8V 20Ah

  • Número do modelo da bateria: 12.8V 20Ah
  • Tensão nominal: 12,8V
  • Capacidade nominal: 20Ah
  • Capacidade de energia (Wh): 256Wh
  • Faixa de tensão operacional: 10V-14,6V
  • Corrente máxima de carga: 20A
  • Corrente máxima de descarga: 20A
  • Dimensão (C x L x A): 181*77*167mm
  • Peso unitário: 2,2Kg
  • Nível de proteção IP: IP65
  • Ciclo de vida: 4000 vezes
  • Tipo de terminal: F23
  • Faixa de temperatura de carga: 0~45℃
  • Faixa de temperatura de descarga: -20~60℃

Aplicação da bateria LiFePO4 12.8V20Ah:

  • Acampamento
  • Sistema Solar Off-grid
  • Sistema Solar Residencial
  • UPS
  • Backup
