MOTOMA energy technology

230伏逆变器

4千瓦光伏MPPT太阳能逆变器4000瓦离网24伏230伏4000瓦纯正弦波

230伏逆变器

4kW光伏MPPT太阳能逆变器，4000W，离网，24V/230V。

  • 额定功率: 4千瓦 24伏
  • 光伏阵列功率: 5000瓦
  • MPPT范围 60 - 450伏直流
  • 双输出智能负载管理
  • 太阳能充电 120安
  • 交流充电 100安
SKU: Axpert VM3 TWIN 4 KW 分类: , 标签: ,, , , , ,
Category
230伏逆变器

4kW光伏MPPT太阳能逆变器，4000W，离网，24V/230V。

概述

Axpert VM III TWIN 配备双路输出。第二路输出可通过LCD设置进行定时开关、设置截止电压或SOC以及放电时间。便于用户进行智能负载控制。设计采用27A光伏输入电流，Axpert VM III TWIN 符合太阳能电池板中Imp增加的市场趋势。它还允许宽范围的光伏输入电压，从60VDC到450VDC。这些特点使得系统中所需太阳能电池板数量减少，节省空间。

主要特性

  • 智能负载管理的双输出
  • 最大光伏输入电流27A
  • 宽光伏输入电压范围60VDC～450VDC
  • 带多种通信的可拆卸LCD控制模块
  • 内置Wi-Fi用于移动监控（App可用）
  • 支持USB On-the-Go功能
  • 为BMS预留的通信端口（RS-485、CAN-BUS或RS-232）
  • 电池均衡延长寿命
  • 电池独立性
  • 用户友好的LCD操作
  • 可更换风扇设计
  • 2年质保
